Police CSVN11 Wheeled Armoured Vehicle

Product Information

• Main Features
• ■ High maneuverability by adopting military highly maneuverable cross-country chassis, it can perform combat tasks in various complicated landforms.
• ■ Spacious internal space allow for accommodating10 persons.
• ■ Flexible weapon and equipment configuration provides various variant retrofit possibilities.
• ■All-round armor protection
• Product catalog
• Police CSVN11 Wheeled Armoured Vehicle Description
• By adopting 4×4 light high maneuverability cross-country chassis and integral armor body, CS/VN11 wheeled armored vehicle can accommodate machine gun, grenade launcher, acousto-optic dispersing device and communication system. Equipped with various equipments as per mission requirements, it can be configured into multi-purpose vehicle to satisfy various operational needs. It mainly implements missions such as anti-terrorism assault, personnel carrying, riot control, armed patrol, defense of critical, command and control, etc.
• Specifications
• ■ Drive Type 4×4
• ■ Crew 2+8
• ■ Full Combat Weight 6300kg
• ■ Protection Type Armoured Steel plate+ Bullet-proof glass
• ■ Ballistic Protection NATO STANAG4569 Level I
• ■ Engine Power 147kW@2500rpm
• ■ Transmission Automatic or manual
• ■ Suspension Dual lateral arm independent suspension
• ■ Steering System Hydraulic power boosted
• ■ Optional Weapon System
• ■ 7.62mm/12.7mm/14.5mm machine gun
• ■ 7.62mm/12.7mm/14.5mmrotating barrel machine gun
• ■ 12.7mm remote weapon system
• ■ Grenade launcher/Acousto-optic disperse device/RF jamming device
• ■ Max.Climbing gradient 60%
• ■ Trench Crossing 700mm
• ■ Vertical Obstacle Crossing 450mm
• ■ Fording Depth 750mm
• ■ Max.Driving Range 600km
• ■ Max.Speed 120km/h
