Ambulance TBT01

Product Information

• The
• is a high-performance emergency medical vehicle designed for rapid patient transport and critical care. Built with a
• fuel-efficient Mitsubishi engine
• , it balances power and reliability for urgent response scenarios. Its sleek, professional exterior houses a
• bridge-style control console
• for streamlined operator access and efficient workflow.
• Equipped with
• advanced medical devices
• (optional), including a patient monitor, defibrillator, transport ventilator, and video laryngoscope, it ensures life-saving interventions en route. Additional essentials like a spine board, head immobilizer, and comprehensive first-aid kit enhance trauma readiness. Designed for versatility, the TBT01 adapts to urban or remote emergencies, prioritizing patient stability and caregiver efficiency. Ideal for hospitals, disaster teams, or EMS units, it combines durability, advanced medical capabilities, and rapid deployment in critical situations.
• Product catalog
• Ambulance 01 Details
• BASIS
• INFORMATION
• 1
• Max.Speed(km/h)
• 130
• 2
• Fuel customer (L/100km)
• 9.3
• 3
• Min.turning radius (m)
• 6.4
• 4
• Angle of Approach/Departure(°)
• 42/33;42/29
• 5
• Max. Slop(%)
• ≥60
• 6
• Body color
• ○
• BODY
• DIMENSION
• 1
• L/W/H(mm)
• 5230/1960/2130
• 2
• Wheel base(mm)
• 3035
• 3
• Tread(F/R)(mm)
• 1540/1540
• 4
• Min ground clearance(mm)
• 225
• 5
• Passenger( person)
• 2+4
• 6
• Curb weight(kg)
• 2000
• 7
• Gross Weight (kg)
• 3680
• 8
• Fuel tank capicity (L)
• 75
• ENGINE
• DIMENSION
• 1
• Engine model
• JE4D25E
• 2
• Engine type
• Four cylinder in line,Turbo charge,water cooling,HPCR
• 3
• Rated. power(kw/rpm)
• 100/3800
• 4
• max. Torque(N.m/rpm)
• 340/(2000)
• 5
• Displacement(L)
• 2.499
• 6
• Fuel
• diesel
• 7
• Emission
• Euro V
