Armored Vehicle 03

Product Information

• The
• is a robust and versatile light-duty vehicle engineered for demanding environments. Its durable construction and elevated ground clearance ensure reliable performance across various terrains. Equipped with a part-tim
• e 4WD system
• and a heavy-duty suspension, it offers enhanced traction and stability. Safety features include dual front airbags, reinforced side impact protection, and emergency flashers. The interior accommodates three occupants, providing practical amenities such as air conditioning, a cooled glove box, and a day/night rearview mirror. Additional features like a snorkel for deep water crossings and a high-altitude compensator enhance its adaptability, making it well-suited for both
• commercial and tactical
• applications.
• Product catalog
• Armored Vehicle 03 Details
• Dimensions
• Length x Width x Height: 5235 × 1770 × 1970 mm
• Deck Dimensions: 2235 × 1600 × 415 mm
• Wheel Base: 3180 mm
• Ground Clearance: 235 mm
• Min. Turning Radius: 7.2 m
• Kerb Weight: 2090 kg
• Payload: 1.0 ton
• Gross Vehicle Weight: 3200 kg
• Engine & Drivetrain
• Displacement: 4164 cc
• Power: 128 HP @ 3800 RPM
• Torque: 29.0 kg·m @ 2200 RPM
• Engine Type: 6-cylinder OHC with fuel injection
• Fuel & Transmission
• Fuel Type: Diesel
• Fuel Tank Capacity: 90+90 L (twin tanks)
• Transmission: 5-speed manual
• 4WD Options: Part-time
• Suspension & Brakes
• Front Suspension: Heavy-duty coil spring
• Rear Suspension: Heavy-duty leaf spring
• Front Brakes: Ventilated disk
• Rear Brakes: Drum with LSPV
• Differential: Rear limited slip
• Tires & Wheels
• Tire Size: 7.50R16-8
• Wheels: Steel grey painted
• Safety
• Airbags: Driver + front passenger
• Seat Belts: Driver + 2 passengers
• Side Impact Beam: Included
• Emergency Flashers: Included
• Exterior
• Bumpers: Front + rear
• Mud Guards: Front + rear
• Side Steps: Included
• Snorkel: For deep water crossing
• Interior
• Seating Capacity: 3 persons
• Seat Material: Fabric
• Accessory Meter: Sub fuel tank
• Cooled Glove Box: Included
• Digital Clock: Included
• Rear View Mirror: Day/night mode
• Sun Visor: Driver + passenger
• Front Door Vent Window: Included
• Electrical
• Windshield Wiper: With mister
• Radio: AM/Medium Wave
• Speakers: 1
• Air Conditioning: Included
• Heater: Included
• Additional Features
• High Altitude Compensator: Included
• Power Steering: Tilt/telescopic
